Technical Data
- Manufacturing Std : BS 1873
- Face to Face, End to End : ASME B16.10
- End Connection : Flanged Ends to ASME B16.5, RF
- End Connection : Butt Weld Ends to ASME B16.25
- Inspection and Testing Std : BS 6755 (Part-1)
|
TESTING PRESSURE |
||||
|
TESTING |
HYDRAULIC |
PNEUMATIC |
||
|
|
150# |
300# |
600# |
|
|
BODY |
450 PSIG |
1125 PSIG |
2225 PSIG |
- |
|
BACK SEAT |
315PSIG |
825 PSIG |
1600 PSIG |
- |
|
SEAT |
315PSIG |
825 PSIG |
1640 PSIG |
80 PSIG |
