Technical Data
- Manufacturing Std : BS 1873 / DIN 3356
- Face to Face : DIN 3202 (Part -1)
- End Connection : Flanged Ends to DIN 2545 (PN 40)
- Inspection and Testing Std : BS 6755 (Part-1)
|
TESTING PRESSURE Kg / Sq.cm. |
|||
|
TESTING |
HYDRAULIC |
PNEUMATIC |
|
|
|
PN 16 |
PN 40 |
|
|
BODY |
24 |
60 |
- |
|
BACK SEAT |
16 |
40 |
- |
|
SEAT |
16 |
40 |
7 |
